Hot melt adhesive labeling machines are suitable for decorating containers with wrap-around roll labels. The labeling machine has a linear design with a precisely operated labeling station that cuts film or paper labels and sticks them to containers using hot-melt glue. In terms of efficiency, accuracy and speed, this labeling machine is suitable for PET mineral water bottles, drinking water bottles, beverage bottles, juice bottles, tea beverage bottles, etc.

FEATURES DESCRIPTION:

1. The speed is flexible and can be adjusted to 36,000 bottles per hour;

2. Rotary design, compact structure, beautiful appearance, wrapped by acid and alkali resistant stainless steel;

3. Simple and quick replacement of configuration components and different containers and labels;

4. It adopts automatic screw bottle conveying device, which has a large working space. The container can complete the adjustment of multiple gestures at one time. The device for adjusting the brush plate is very simple, and the maintenance is simple and convenient;

5. Using the roller labeling method, the label is conveyed through the label wheel and runs along the guide rail to carry out the labeling work;

6. When the label passes the designated wheel, the sensor will automatically detect;

7. Once the position of the electronic eye is determined, the demodulator will automatically adjust the speed of the wheel, and then accurately specify the label cutting position;

8. The label enters the cutting part through the wheel for label cutting, and the cut label will be sent to the vacuum grabbing cylinder;

9. The containers conveyed by the conveyor belt are arranged neatly through the star wheel, and the glued labels are labeled in the roller area for the first time, and finally rely on the synchronous belt for the last labeling operation;

10. Imported control system, servo or step-in labeling system, with high-end configuration of automatic test label label stop, can ensure stable operation of the equipment, and other brands can be selected according to the actual needs of customers;

11. The cylinder drives the rotary bottle structure, and the rotary three-positioning method ensures excellent labeling parallelism and positioning accuracy;

12. The main material is made of stainless steel and high-grade aluminum alloy, which is produced in accordance with GMP standards. The structure is firm and beautiful.

OPERATION METHOD:

Containers are picked up by the infeed star wheel and transferred to the container table. When they are between the container plate and the centering bell, the container starts to rotate.

Feed roller speed is adjusted to the required label length for continuous web force. The standard threading device ensures optimum film feed. In the cutting unit, the labels are cut precisely, while PLC commands and servo motors provide the precise cutting point.

Two narrow strips of hot-melt adhesive hold the label together, and a heated roller passes the label to the leading and trailing edges of the label. Labels with an adhesive strip on the leading edge are transferred to the container. This adhesive strip ensures accurate label positioning and reliable bonding. Labels are tightly attached as containers are rotated during label transfer. Glue the trailing edge to ensure proper bonding.

TECHNICAL PARAMETER:

Name	OPP Hot Melt Labeling Machine
Power supply	Three-phase 380V 60Hz 5KW
Machine dimensions:	3650mm1700mm2010mm( can be adjusted by customer requirements)
Method of speed adjustment:	uninterrupted - adjust rate
Labeling precision:	±1mm
Labeling speed	8000-24000bph
Maximum label width:	200mm(standard width, can be adjusted )
The maximum outer diameter of label	600mm
Paper core Hot melt	152 mm
Labeling glue:	glue at both ends of each label with hot melt
Gluing temperature:	120~160ºC
Labeling type for products:	suitable for round or square containers made of plastic, metal, glass
Type of label:	BOPP, paper-plastic composite film, paper label
Labeling stations:	12per cycle
Machine weight:	3000 kg

Mechanical Parts

Transportation institution	Motor 0.75KW with deceleration, inverter speed control
Conveyor	Industrial nylon chain plate conveyor
Mainframe transportation institution	Motor 2.2Kw with deceleration
Sub bottle institution	Industrial worm sub bottle institution
Into bottle institution	With worm sub bottle institution and starwheel position feeding institution to ensure the accuracy and stability of loading
Position institution	Mechanical pre-location , using the camwheel institution to planish the bottle for label positioning
Labeling institution	Containers are pick up by rotary wheel ,labeling during the rotation.
Supply label institution	High speed servo opp label supply system (drive by servo-motor)
Pressing label institution	Arc brush unit
Guided bottle institution	Adjust by double coordinate section guide rail
Glue supply system	Hot melt glue supply system ensures the accuracy and uniformity of gluing

Safety protection	In order to keep the operator safety ,when the machine is running please close the protective doors
Lack of label alarm	Set an alarm to remind the operator to change the label when the label will be use out
Lack of bottle alarm	When lack of the bottle the machine will stop and make an alarm .The machine will restart automatically as soon as the bottles have been put that will facilitate on-line production
Leak of labeling alarm	To control the quality of labeling
Pressure testing	When the pressure can not meet the equipment requirement ,the machine will stop to against bad products produce
Vacuum testing	When the vacuum can not meet the equipment requirement ,the machine will stop to against bad products produce
Temperature testing	When the temperature can not meet the equipment requirement , the machine will stop to against bad products produce

Safety parts

This labeling machine is a fully automatic hot-melt labeling linear machine, which is suitable for different container sizes and round bottle shapes. The system has high labeling accuracy and less glue consumption. Switching to a different container or label is quick and easy. All modified adjustments are easily reproducible. The labeling machine is easy to operate, clean and maintain, and can generate high economic benefits due to its high reliability.
